INA PWTR3072-2RS-RR-XL Image 4
Visual product photo and picture of the product.
Price: 119.66 $
Specifications
Weight and Dimensions
| Inner (d) MM |
30 |
| Outer (D) MM |
72 |
| Width (B) MM |
28 |
| Inner (d) Inch |
1.1811 |
| Outer (D) Inch |
2.8346 |
| Width (B) Inch |
1.1024 |
| Weight (kg) |
0.697 kg
|
Product Properties
| Seal |
2RS - Rubber Seal on Two Sides |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Width inner ring (B) mm |
29 |
| Basic dynamic load rating, radial (C r w) |
41000 |
| Basic static load rating, radial (C 0r) |
56000 |
| Speed on permanent grease lubrication (n D G) |
2200 |
| ECLASS number |
23-05-15-01 |
| ECLASS2 number |
23-05-15-01 |
| Medias description |
Yoke type track rollers PWTR..-2RS-RR, Full complement cylindrical roller set, with axial guidance, lip seal on both sides, with Corrotect coating |
Suffix description
| 2RS |
Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103 |
| RR |
Protected Against Corrosion By Corrotect® Special Coating |
| XL |
X-Life |
