INA PWKRE52-2RS-RR-XL Image 3
Visual product photo and picture of the product.
Price: 160.78 $
Specifications
Weight and Dimensions
| Inner (d) MM |
20 |
| Outer (D) MM |
52 |
| Width (B) MM |
24 |
| Inner (d) Inch |
0.7874 |
| Outer (D) Inch |
2.0472 |
| Width (B) Inch |
0.9449 |
| Weight (kg) |
0.528 kg
|
Product Properties
| Seal |
2RS - Rubber Seal on Two Sides |
| Excenterring |
E - Excenterring with Inbus Mount |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
20 |
| Width (b) mm |
66 |
| Basic dynamic load rating, radial (C r w) |
25500 |
| Basic static load rating, radial (C 0r) |
33500 |
| Speed on permanent grease lubrication (n D G) |
3800 |
| ECLASS number |
23-05-15-02 |
| ECLASS2 number |
23-05-15-02 |
| Medias description |
Yoke type track roller PWKRE..-2RS-RR-XL, full complement roller set, two-row, with axial guidance, with eccentric, pallet changer |
Suffix description
| 2RS |
Rubber Seals At Each Side Of The Bearing, Temperature Range -30u2103/+120u2103 |
| RR |
Protected Against Corrosion By Corrotect® Special Coating |
| XL |
X-Life |
