INA PWKR40-2RS-RR-XL Image 4
Visual product photo and picture of the product.
Price: 114.40 $
Specifications
Weight and Dimensions
| Inner (d) MM |
18 |
| Outer (D) MM |
40 |
| Width (B) MM |
20 |
| Inner (d) Inch |
0.7087 |
| Outer (D) Inch |
1.5748 |
| Width (B) Inch |
0.7874 |
| Weight (kg) |
0.242 kg
|
Product Properties
| Seal |
2RS - Rubber Seal on Two Sides |
| Excenterring |
Other Mounting Method |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
18 |
| Width (b) mm |
58 |
| Basic dynamic load rating, radial (C r w) |
14300 |
| Basic static load rating, radial (C 0r) |
18200 |
| Speed on permanent grease lubrication (n D G) |
5000 |
| ECLASS number |
23-05-15-02 |
| ECLASS2 number |
23-05-15-02 |
| Medias description |
Stud type track rollers PWKR..-2RS-RR, With axial guidance, full complement cylindrical roller set, lip seal on both sides, with Corrotect coating |
Suffix description
| 2RS |
Rubber Seals At Each Side Of The Bearing, Temperature Range -30u2103/+120u2103 |
| RR |
Protected Against Corrosion By Corrotect® Special Coating |
| XL |
X-Life |
