INA PWKR35-2RS-XL Image 3
Visual product photo and picture of the product.
Price: 57.08 $
Specifications
Weight and Dimensions
| Inner (d) MM |
16 |
| Outer (D) MM |
35 |
| Width (B) MM |
18 |
| Inner (d) Inch |
0.6299 |
| Outer (D) Inch |
1.378 |
| Width (B) Inch |
0.7087 |
| Weight (kg) |
0.164 kg
|
Product Properties
| Seal |
2RS - Rubber Seal on Two Sides |
| Excenterring |
Other Mounting Method |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
16 |
| Width (b) mm |
52 |
| Basic dynamic load rating, radial (C r w) |
12500 |
| Basic static load rating, radial (C 0r) |
14900 |
| Speed on permanent grease lubrication (n D G) |
6000 |
| ECLASS number |
23-05-15-02 |
| ECLASS2 number |
23-05-15-02 |
| Medias description |
Stud type track rollers PWKR..-2RS, with axial guidance, full complement cylindrical roller set, lip seals on both sides |
Suffix description
| 2RS |
Rubber Seals At Each Side Of The Bearing, Temperature Range -30u2103/+120u2103 |
| XL |
X-Life |
