INA NKI55/25-TV-XL Image 4

Visual product photo and picture of the product.

INA NKI55/25-TV-XL bearing image 4
INA NKI55/25-TV-XL bearing image 1
INA NKI55/25-TV-XL bearing image 2
INA NKI55/25-TV-XL bearing image 3
INA NKI55/25-TV-XL bearing image 4
INA NKI55/25-TV-XL bearing image 5
INA NKI55/25-TV-XL bearing image 6
Price: 44.99 $
Specifications
Brand INA
Item Number NKI55/25-TV-XL INA
Manufacturer Part Number 0507624510000
Also known as NKI55/25-TV
EAN 4012802701890
Category Needle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM 55
Outer (D) MM 72
Width (B) MM 25
Inner (d) Inch 2.1654
Outer (D) Inch 2.8346
Width (B) Inch 0.9843
Weight (kg) 0.272 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width (b) mm 25
Radial Static Load Rating C0r (N) 103000
Radial Dynamic Load Rating Cr (N) 53000
Limiting speed (n G) 7700
Reference speed (n u03d1r) 4400
ECLASS number 23-05-09-07
ECLASS2 number 23-05-09-07
Medias description Needle roller bearings NKI, light series
Suffix description
TV Polyamide Cage
XL X-Life
