INA NKI50/35-XL-C3 Image 3

Visual product photo and picture of the product.

INA NKI50/35-XL-C3 bearing image 3
INA NKI50/35-XL-C3 bearing image 1
INA NKI50/35-XL-C3 bearing image 2
INA NKI50/35-XL-C3 bearing image 3
INA NKI50/35-XL-C3 bearing image 4
INA NKI50/35-XL-C3 bearing image 5
Price: 51.66 $
Specifications
Brand INA
Item Number NKI50/35-XL-C3 INA
Manufacturer Part Number 0507624430030
Also known as NKI50/35-C3
EAN 4012802701883
Category Needle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 68
Width (B) MM 35
Inner (d) Inch 1.9685
Outer (D) Inch 2.6772
Width (B) Inch 1.378
Weight (kg) 0.379 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width (b) mm 35
Radial Static Load Rating C0r (N) 118000
Radial Dynamic Load Rating Cr (N) 60000
Basic static load rating, radial (C 0r) "118000.0000"
Limiting speed (n G) 8400
Reference speed (n u03d1r) 4900
ECLASS number 23-05-09-07
ECLASS2 number 23-05-09-07
Medias description Needle roller bearings NKI, light series
Suffix description
XL X-Life
C3 Internal Clearance Larger Than Normal
