Price: 26.73 $
Specifications
Brand INA
Item Number NKI40/20-TV-XL INA
Manufacturer Part Number 0507622730000
Also known as NKI40/20-TV
EAN 4012802701678
Category Needle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 55
Width (B) MM 20
Inner (d) Inch 1.5748
Outer (D) Inch 2.1654
Width (B) Inch 0.7874
Weight (kg) 0.142 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width (b) mm 20
Radial Static Load Rating C0r (N) 62000
Radial Dynamic Load Rating Cr (N) 35000
Basic static load rating, radial (C 0r) "62000.0000"
Limiting speed (n G) 10200
Reference speed (n u03d1r) 5600
ECLASS number 23-05-09-07
ECLASS2 number 23-05-09-07
Medias description Needle roller bearings NKI, light series
Suffix description
TV Polyamide Cage
XL X-Life
