Price: 25.28 $
Specifications
Brand INA
Item Number NKI35/20-TV-XL INA
Manufacturer Part Number 0507622220000
Also known as NKI35/20-TV
EAN 4012802310740
Category Needle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM 35
Outer (D) MM 50
Width (B) MM 20
Inner (d) Inch 1.378
Outer (D) Inch 1.9685
Width (B) Inch 0.7874
Weight (kg) 0.127 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width (b) mm 20
Radial Static Load Rating C0r (N) 56000
Radial Dynamic Load Rating Cr (N) 33500
Basic static load rating, radial (C 0r) "56000.0000"
Limiting speed (n G) 11400
Reference speed (n u03d1r) 6100
ECLASS number 23-05-09-07
ECLASS2 number 23-05-09-07
Medias description Needle roller bearings NKI, light series
Suffix description
TV Polyamide Cage
XL X-Life
