INA NKI25/20-TV-XL bearing image 3
INA NKI25/20-TV-XL bearing image 1
INA NKI25/20-TV-XL bearing image 2
INA NKI25/20-TV-XL bearing image 3
INA NKI25/20-TV-XL bearing image 4
INA NKI25/20-TV-XL bearing image 5
Price: 18.19 $
Specifications
Brand INA
Item Number NKI25/20-TV-XL INA
Manufacturer Part Number 0507621410000
Also known as NKI25/20-TV
EAN 4012802734409
Category Needle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 38
Width (B) MM 20
Inner (d) Inch 0.9843
Outer (D) Inch 1.4961
Width (B) Inch 0.7874
Weight (kg) 0.079 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width (b) mm 20
Radial Static Load Rating C0r (N) 39000
Radial Dynamic Load Rating Cr (N) 27500
Basic static load rating, radial (C 0r) "39000.0000"
Limiting speed (n G) 15300
Reference speed (n u03d1r) 8100
ECLASS number 23-05-09-07
ECLASS2 number 23-05-09-07
Medias description Needle roller bearings NKI, light series
Suffix description
TV Polyamide Cage
XL X-Life
