INA NATV12-PP-A Image 4
Visual product photo and picture of the product.
Price: 33.58 $
Specifications
Weight and Dimensions
| Inner (d) MM |
12 |
| Outer (D) MM |
32 |
| Width (B) MM |
14 |
| Inner (d) Inch |
0.4724 |
| Outer (D) Inch |
1.2598 |
| Width (B) Inch |
0.5512 |
| Weight (kg) |
0.072 kg
|
Product Properties
| Seal |
2L - LS-seal at Both Sides |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Width of the bearing (B) mm |
15 |
| Basic dynamic load rating, radial (C r w) |
9600 |
| Basic static load rating, radial (C 0r) |
15900 |
| Speed on permanent grease lubrication (n D G) |
1800 |
| ECLASS number |
23-05-15-01 |
| ECLASS2 number |
23-05-15-01 |
| Medias description |
Yoke type track rollers NATV..-PP, full complement needle roller set, with axial guidance, axial plain washers on both sides |
Suffix description
| PP |
Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded), Temperature Range -30 ~ 100u2103 |
| A |
Alteration In Internal Construction. Identical To Old Notation |
