INA NA4924-XL-C3 Image 6

Visual product photo and picture of the product.

INA NA4924-XL-C3 bearing image 6
INA NA4924-XL-C3 bearing image 1
INA NA4924-XL-C3 bearing image 2
INA NA4924-XL-C3 bearing image 3
INA NA4924-XL-C3 bearing image 4
INA NA4924-XL-C3 bearing image 5
INA NA4924-XL-C3 bearing image 6
INA NA4924-XL-C3 bearing image 7
Price: 279.59 $
Specifications
Brand INA
Item Number NA4924-XL-C3 INA
Manufacturer Part Number 0506616710030
Also known as NA4924-C3
EAN 4047643205429
Category Needle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM 120
Outer (D) MM 165
Width (B) MM 45
Inner (d) Inch 4.7244
Outer (D) Inch 6.4961
Width (B) Inch 1.7717
Weight (kg) 2.883 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width (b) mm 45
Basic static load rating, radial (C 0r) 390000
Limiting speed (n G) 3400
Limiting speed for grease lubrication (n G Grease) 2040
Reference speed (n u03d1r) 2160
ECLASS number 23-05-09-07
ECLASS2 number 23-05-09-07
Suffix description
XL X-Life
C3 Internal Clearance Larger Than Normal
