INA KWVE45-B-SN-V1-G2 Image 5

Visual product photo and picture of the product.

INA KWVE45-B-SN-V1-G2 bearing image 5
INA KWVE45-B-SN-V1-G2 bearing image 1
INA KWVE45-B-SN-V1-G2 bearing image 2
INA KWVE45-B-SN-V1-G2 bearing image 3
INA KWVE45-B-SN-V1-G2 bearing image 4
INA KWVE45-B-SN-V1-G2 bearing image 5
Price: 177.72 $
Specifications
Brand INA
Item Number KWVE45-B-SN-V1-G2 INA
Manufacturer Part Number 0200784390230
Also known as KWVE45-B-SN-G2-V1
EAN 4054366343604
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 86
Width (B) MM 140,6
Inner (d) Inch 1.7717
Outer (D) Inch 3.3858
Width (B) Inch 5.5354
Weight (kg) 2.12 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 86
Overall length carriage (L) mm 140,6
Dynamic load rating (C) 69000
Static load rating (C 0) 141000
Static moment rating about X axis (M 0x) 3610
Static moment rating about Y axis (M 0y) 2485
Static moment rating about Z axis (M 0z) 2485
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-SN, narrow, low carriage, four-row
Suffix description
B Version
SN Narrow, Low Carriage
V1 Slight Preload
G2 Precision Class 2
