INA KWVE45-B-RROC-V2-G3 Image 5
Visual product photo and picture of the product.
Price: 209.04 $
Specifications
Weight and Dimensions
| Inner (d) MM |
45 |
| Outer (D) MM |
120 |
| Width (B) MM |
50,3 |
| Inner (d) Inch |
1.7717 |
| Outer (D) Inch |
4.7244 |
| Width (B) Inch |
1.9803 |
| Weight (kg) |
3.3 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
120 |
| Overall length carriage (L) mm |
140,6 |
| Dynamic load rating (C) |
69000 |
| Static load rating (C 0) |
141000 |
| Static moment rating about X axis (M 0x) |
3610 |
| Static moment rating about Y axis (M 0y) |
2485 |
| Static moment rating about Z axis (M 0z) |
2485 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B, standard carriage, four-row, full complement ball set |
Suffix description
| B |
Version |
| RROC |
Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free |
| V2 |
Preload Class 2 |
| G3 |
Precision Class 3 |
