INA KWVE35-B-V1-G1

INA KWVE35-B-V1-G1
INA KWVE35-B-V1-G1 rulman resim 1
INA KWVE35-B-V1-G1 rulman resim 2
INA KWVE35-B-V1-G1 rulman resim 3
INA KWVE35-B-V1-G1 rulman resim 4
INA KWVE35-B-V1-G1 rulman resim 5
Price: 156.97 $
Specifications
Brand INA
Item Number KWVE35-B-V1-G1 INA
Manufacturer Part Number 0174205550220
Also known as KWVE35-B-G1-V1
EAN 4054366324849
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 34
Outer (D) MM 100
Width (B) MM 112
Inner (d) Inch 1.3386
Outer (D) Inch 3.937
Width (B) Inch 4.4094
Weight (kg) 1.75 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 100
Overall length carriage (L) mm 112
Dynamic load rating (C) 38000
Static load rating (C 0) 72000
Static moment rating about X axis (M 0x) 1465
Static moment rating about Y axis (M 0y) 1020
Static moment rating about Z axis (M 0z) 1020
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B, standard carriage, four-row, full complement ball set
Suffix description
B Version
V1 Slight Preload
G1 Precision Class 1
