INA KWVE35-B-N-RROC-V2-G3

INA KWVE35-B-N-RROC-V2-G3
INA KWVE35-B-N-RROC-V2-G3 rulman resim 1
INA KWVE35-B-N-RROC-V2-G3 rulman resim 2
INA KWVE35-B-N-RROC-V2-G3 rulman resim 3
INA KWVE35-B-N-RROC-V2-G3 rulman resim 4
INA KWVE35-B-N-RROC-V2-G3 rulman resim 5
Price: 181.96 $
Specifications
Brand INA
Item Number KWVE35-B-N-RROC-V2-G3 INA
Manufacturer Part Number 0782428600340
Also known as KWVE35-B-N-RROC-G3-V2
EAN 4054366883247
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 34
Outer (D) MM 100
Width (B) MM 112
Inner (d) Inch 1.3386
Outer (D) Inch 3.937
Width (B) Inch 4.4094
Weight (kg) 1.56 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 100
Overall length carriage (L) mm 112
Dynamic load rating (C) 38000
Static load rating (C 0) 72000
Static moment rating about X axis (M 0x) 1465
Static moment rating about Y axis (M 0y) 1020
Static moment rating about Z axis (M 0z) 1020
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-N, low carriage, four-row
Suffix description
B Version
N Low Carriage
RROC Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
V2 Preload Class 2
G3 Precision Class 3
