INA KWVE35-B-SL-V2-G2 Image 5
Visual product photo and picture of the product.
Price: 179.60 $
Specifications
Weight and Dimensions
| Inner (d) MM |
34 |
| Outer (D) MM |
70 |
| Width (B) MM |
145 |
| Inner (d) Inch |
1.3386 |
| Outer (D) Inch |
2.7559 |
| Width (B) Inch |
5.7087 |
| Weight (kg) |
1.81 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
70 |
| Overall length carriage (L) mm |
145 |
| Dynamic load rating (C) |
47500 |
| Static load rating (C 0) |
100000 |
| Static moment rating about X axis (M 0x) |
2625 |
| Static moment rating about Y axis (M 0y) |
1890 |
| Static moment rating about Z axis (M 0z) |
1890 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-SL, narrow, long carriage, four-row |
Suffix description
| B |
Version |
| SL |
Narrow, Long Carriage |
| V2 |
Preload Class 2 |
| G2 |
Precision Class 2 |
