INA KWVE35-B-S-V2-G2 Image 2

Visual product photo and picture of the product.

INA KWVE35-B-S-V2-G2 bearing image 2
INA KWVE35-B-S-V2-G2 bearing image 1
INA KWVE35-B-S-V2-G2 bearing image 2
INA KWVE35-B-S-V2-G2 bearing image 3
INA KWVE35-B-S-V2-G2 bearing image 4
INA KWVE35-B-S-V2-G2 bearing image 5
Price: 141.42 $
Specifications
Brand INA
Item Number KWVE35-B-S-V2-G2 INA
Manufacturer Part Number 0183558380330
Also known as KWVE35-B-S-G2-V2
EAN 4054366333544
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 34
Outer (D) MM 70
Width (B) MM 112
Inner (d) Inch 1.3386
Outer (D) Inch 2.7559
Width (B) Inch 4.4094
Weight (kg) 1.3 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 70
Overall length carriage (L) mm 112
Dynamic load rating (C) 38000
Static load rating (C 0) 72000
Static moment rating about X axis (M 0x) 1465
Static moment rating about Y axis (M 0y) 1020
Static moment rating about Z axis (M 0z) 1020
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-S, narrow carriage, four-row
Suffix description
B Version
S Narrow Carriage
V2 Preload Class 2
G2 Precision Class 2
