INA KWVE35-B-E-V2-G3 Image 3

Visual product photo and picture of the product.

INA KWVE35-B-E-V2-G3 bearing image 3
INA KWVE35-B-E-V2-G3 bearing image 1
INA KWVE35-B-E-V2-G3 bearing image 2
INA KWVE35-B-E-V2-G3 bearing image 3
INA KWVE35-B-E-V2-G3 bearing image 4
INA KWVE35-B-E-V2-G3 bearing image 5
Price: 125.52 $
Specifications
Brand INA
Item Number KWVE35-B-E-V2-G3 INA
Manufacturer Part Number 0605850640340
Also known as KWVE35-B-E-G3-V2
EAN 4054366781642
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 41,3
Outer (D) MM 100
Width (B) MM 112
Inner (d) Inch 1.626
Outer (D) Inch 3.937
Width (B) Inch 4.4094
Weight (kg) 1.893 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 100
Overall length carriage (L) mm 112
Dynamic load rating (C) 38000
Static load rating (C 0) 72000
Static moment rating about X axis (M 0x) 1465
Static moment rating about Y axis (M 0y) 1020
Static moment rating about Z axis (M 0z) 1020
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-E, standard carriage, four-row, full complement, expanded type
Suffix description
B Standard Carriage, Four-Row, Full Complement Ball Set
E Expanded Design (Carriage Without Screw Threads)
V2 Preload Class 2
G3 Precision Class 3
