INA KWVE30-B-S-V1-G4 Image 3

Visual product photo and picture of the product.

INA KWVE30-B-S-V1-G4 bearing image 3
INA KWVE30-B-S-V1-G4 bearing image 1
INA KWVE30-B-S-V1-G4 bearing image 2
INA KWVE30-B-S-V1-G4 bearing image 3
INA KWVE30-B-S-V1-G4 bearing image 4
INA KWVE30-B-S-V1-G4 bearing image 5
Price: 123.04 $
Specifications
Brand INA
Item Number KWVE30-B-S-V1-G4 INA
Manufacturer Part Number 0199747360250
Also known as KWVE30-B-S-G4-V1
EAN 4054366336392
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 28
Outer (D) MM 60
Width (B) MM 36,1
Inner (d) Inch 1.1024
Outer (D) Inch 2.3622
Width (B) Inch 1.4213
Weight (kg) 0.94 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 60
Overall length carriage (L) mm 99
Dynamic load rating (C) 27500
Static load rating (C 0) 55000
Static moment rating about X axis (M 0x) 970
Static moment rating about Y axis (M 0y) 700
Static moment rating about Z axis (M 0z) 700
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-S, narrow carriage, four-row
Suffix description
B Version
S Narrow Carriage
V1 Slight Preload
G4 Precision Class 4
