INA KWVE30-B-N-V0-G1 Image 3

Visual product photo and picture of the product.

INA KWVE30-B-N-V0-G1 bearing image 3
INA KWVE30-B-N-V0-G1 bearing image 1
INA KWVE30-B-N-V0-G1 bearing image 2
INA KWVE30-B-N-V0-G1 bearing image 3
INA KWVE30-B-N-V0-G1 bearing image 4
INA KWVE30-B-N-V0-G1 bearing image 5
Price: 149.91 $
Specifications
Brand INA
Item Number KWVE30-B-N-V0-G1 INA
Manufacturer Part Number 0199761510120
Also known as KWVE30-B-N-G1-V0
EAN 4054362999348
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 28
Outer (D) MM 90
Width (B) MM 99
Inner (d) Inch 1.1024
Outer (D) Inch 3.5433
Width (B) Inch 3.8976
Weight (kg) 1 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 90
Overall length carriage (L) mm 99
Dynamic load rating (C) 27500
Static load rating (C 0) 55000
Static moment rating about X axis (M 0x) 970
Static moment rating about Y axis (M 0y) 700
Static moment rating about Z axis (M 0z) 700
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-N, low carriage, four-row
Suffix description
B Version
N Low Carriage
V0 Little To No Preload
G1 Precision Class 1
