INA KWVE30-B-L-V1-G3 Image 2

Visual product photo and picture of the product.

INA KWVE30-B-L-V1-G3 bearing image 2
INA KWVE30-B-L-V1-G3 bearing image 1
INA KWVE30-B-L-V1-G3 bearing image 2
INA KWVE30-B-L-V1-G3 bearing image 3
INA KWVE30-B-L-V1-G3 bearing image 4
INA KWVE30-B-L-V1-G3 bearing image 5
Price: 170.17 $
Specifications
Brand INA
Item Number KWVE30-B-L-V1-G3 INA
Manufacturer Part Number 0171747160240
Also known as KWVE30-B-L-G3-V1
EAN 4054362997849
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 28
Outer (D) MM 90
Width (B) MM 127
Inner (d) Inch 1.1024
Outer (D) Inch 3.5433
Width (B) Inch 5
Weight (kg) 1.7 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 90
Overall length carriage (L) mm 127
Dynamic load rating (C) 34500
Static load rating (C 0) 74000
Static moment rating about X axis (M 0x) 1310
Static moment rating about Y axis (M 0y) 1240
Static moment rating about Z axis (M 0z) 1240
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-L, long carriage, four-row, full complement ball set
Suffix description
B Version
L Long Carriage
V1 Slight Preload
G3 Precision Class 3
