INA KWVE25-B-SNL-KD-V2-G3 Image 2
Visual product photo and picture of the product.
Price: 187.57 $
Specifications
Weight and Dimensions
| Inner (d) MM |
23 |
| Outer (D) MM |
48 |
| Width (B) MM |
109,1 |
| Inner (d) Inch |
0.9055 |
| Outer (D) Inch |
1.8898 |
| Width (B) Inch |
4.2953 |
| Weight (kg) |
0.62 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
48 |
| Overall length carriage (L) mm |
109,1 |
| Dynamic load rating (C) |
23400 |
| Static load rating (C 0) |
54000 |
| Static moment rating about X axis (M 0x) |
745 |
| Static moment rating about Y axis (M 0y) |
825 |
| Static moment rating about Z axis (M 0z) |
825 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-SNL, narrow, low, long carriage, four-row |
Suffix description
| B |
Version |
| SNL |
Narrow, Low, Long Carriage |
| KD |
Components Coated With Protect A Have The Suffix KD (Protect A Is A Pure Chromium Coating With A Columnar Surface Structure). When Using Protect A, Coated Carriages And Coated Guideways Must Always Be Combined. If Coated Carriages Are Used With Uncoated Guideways, For Example, This Will Lead To A Reduction In Preload |
| V2 |
Preload Class 2 |
| G3 |
Precision Class 3 |
