INA KWVE25-B-NL-V0-G4 Image 2

Visual product photo and picture of the product.

INA KWVE25-B-NL-V0-G4 bearing image 2
INA KWVE25-B-NL-V0-G4 bearing image 1
INA KWVE25-B-NL-V0-G4 bearing image 2
INA KWVE25-B-NL-V0-G4 bearing image 3
INA KWVE25-B-NL-V0-G4 bearing image 4
INA KWVE25-B-NL-V0-G4 bearing image 5
Price: 131.99 $
Specifications
Brand INA
Item Number KWVE25-B-NL-V0-G4 INA
Manufacturer Part Number 0127396340150
Also known as KWVE25-B-NL-G4-V0
EAN 4054362986195
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 23
Outer (D) MM 70
Width (B) MM 109,1
Inner (d) Inch 0.9055
Outer (D) Inch 2.7559
Width (B) Inch 4.2953
Weight (kg) 0.82 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 70
Overall length carriage (L) mm 109,1
Dynamic load rating (C) 23400
Static load rating (C 0) 54000
Static moment rating about X axis (M 0x) 745
Static moment rating about Y axis (M 0y) 825
Static moment rating about Z axis (M 0z) 825
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-NL, low, long carriage, four-row
Suffix description
B Version
NL Low, Long Carriage
V0 Little To No Preload
G4 Precision Class 4
