INA KWVE20-WL-V2-G3 Image 2
Visual product photo and picture of the product.
Price: 163.16 $
Specifications
Weight and Dimensions
| Inner (d) MM |
42 |
| Outer (D) MM |
80 |
| Width (B) MM |
87,3 |
| Inner (d) Inch |
1.6535 |
| Outer (D) Inch |
3.1496 |
| Width (B) Inch |
3.437 |
| Weight (kg) |
0.7 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
80 |
| Overall length carriage (L) mm |
87,3 |
| Dynamic load rating (C) |
16200 |
| Static load rating (C 0) |
36500 |
| Static moment rating about X axis (M 0x) |
920 |
| Static moment rating about Y axis (M 0y) |
400 |
| Static moment rating about Z axis (M 0z) |
400 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-WL, wide, long carriage for linear recirculating ball bearing and guideway assembly |
Suffix description
| WL |
Wide, Long Carriage |
| V2 |
Preload Class 2 |
| G3 |
Precision Class 3 |
