INA KWVE20-B-N-V2-G3 Image 2

Visual product photo and picture of the product.

INA KWVE20-B-N-V2-G3 bearing image 2
INA KWVE20-B-N-V2-G3 bearing image 1
INA KWVE20-B-N-V2-G3 bearing image 2
INA KWVE20-B-N-V2-G3 bearing image 3
INA KWVE20-B-N-V2-G3 bearing image 4
INA KWVE20-B-N-V2-G3 bearing image 5
Price: 107.01 $
Specifications
Brand INA
Item Number KWVE20-B-N-V2-G3 INA
Manufacturer Part Number 0125089180340
Also known as KWVE20-B-N-G3-V2
EAN 4054362972570
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 63
Width (B) MM 71,4
Inner (d) Inch 0.7874
Outer (D) Inch 2.4803
Width (B) Inch 2.811
Weight (kg) 0.37 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 63
Overall length carriage (L) mm 71,4
Dynamic load rating (C) 13100
Static load rating (C 0) 27000
Static moment rating about X axis (M 0x) 332
Static moment rating about Y axis (M 0y) 240
Static moment rating about Z axis (M 0z) 240
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-N, low carriage, four-row
Suffix description
B Version
N Low Carriage
V2 Preload Class 2
G3 Precision Class 3
