Price: 85.41 $
Specifications
Brand INA
Item Number KWVE20-B-ESC-V1-G3 INA
Manufacturer Part Number 0125089500240
Also known as KWVE20-B-ESC-G3-V1
EAN 4054362968191
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 42
Width (B) MM 50,4
Inner (d) Inch 0.7874
Outer (D) Inch 1.6535
Width (B) Inch 1.9843
Weight (kg) 0.18 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 42
Overall length carriage (L) mm 50,4
Dynamic load rating (C) 8900
Static load rating (C 0) 15400
Static moment rating about X axis (M 0x) 190
Static moment rating about Y axis (M 0y) 85
Static moment rating about Z axis (M 0z) 85
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set
Suffix description
B Version
ESC Expanded Design, Short, Narrow Carriage
V1 Slight Preload
G3 Precision Class 3
