INA KWVE20-B-ESC-V0-G1 Image 5
Visual product photo and picture of the product.
Price: 93.98 $
Specifications
Weight and Dimensions
| Inner (d) MM |
20 |
| Outer (D) MM |
42 |
| Width (B) MM |
50,4 |
| Inner (d) Inch |
0.7874 |
| Outer (D) Inch |
1.6535 |
| Width (B) Inch |
1.9843 |
| Weight (kg) |
0.18 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
42 |
| Overall length carriage (L) mm |
50,4 |
| Dynamic load rating (C) |
8900 |
| Static load rating (C 0) |
15400 |
| Static moment rating about X axis (M 0x) |
190 |
| Static moment rating about Y axis (M 0y) |
85 |
| Static moment rating about Z axis (M 0z) |
85 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set |
Suffix description
| B |
Version |
| ESC |
Expanded Design, Short, Narrow Carriage |
| V0 |
Little To No Preload |
| G1 |
Precision Class 1 |
