INA KWVE15-B-H-RROC-V2-G3 Image 3

Visual product photo and picture of the product.

INA KWVE15-B-H-RROC-V2-G3 bearing image 3
INA KWVE15-B-H-RROC-V2-G3 bearing image 1
INA KWVE15-B-H-RROC-V2-G3 bearing image 2
INA KWVE15-B-H-RROC-V2-G3 bearing image 3
INA KWVE15-B-H-RROC-V2-G3 bearing image 4
INA KWVE15-B-H-RROC-V2-G3 bearing image 5
Price: 102.29 $
Specifications
Brand INA
Item Number KWVE15-B-H-RROC-V2-G3 INA
Manufacturer Part Number 0781970820340
Also known as KWVE15-B-H-RROC-G3-V2
EAN 4054362963240
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 15
Outer (D) MM 34
Width (B) MM 61,2
Inner (d) Inch 0.5906
Outer (D) Inch 1.3386
Width (B) Inch 2.4094
Weight (kg) 0.2 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 34
Overall length carriage (L) mm 61,2
Dynamic load rating (C) 7200
Static load rating (C 0) 14500
Static moment rating about X axis (M 0x) 150
Static moment rating about Y axis (M 0y) 100
Static moment rating about Z axis (M 0z) 100
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-H, high, narrow carriage, four-row
Suffix description
B Version
H High Carriage
RRF Components Coated With Corrotect® Containing Cr(VI)
V2 Preload Class 2
G3 Precision Class 3
