Price: 64.02 $
Specifications
Brand INA
Item Number KWVE15-B-EC-V1-G4 INA
Manufacturer Part Number 0197546550250
Also known as KWVE15-B-EC-G4-V1
EAN 4054362961314
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 15
Outer (D) MM 52
Width (B) MM 44,5
Inner (d) Inch 0.5906
Outer (D) Inch 2.0472
Width (B) Inch 1.752
Weight (kg) 0.13 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 52
Overall length carriage (L) mm 44,5
Dynamic load rating (C) 4900
Static load rating (C 0) 8300
Static moment rating about X axis (M 0x) 86
Static moment rating about Y axis (M 0y) 35
Static moment rating about Z axis (M 0z) 35
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-EC, expanded interchangeability, short carriage, four-row
Suffix description
B Version
EC Expanded Design, Short Carriage (Carriage Without Screw Threads)
V1 Slight Preload
G4 Precision Class 4
