INA KWSE45-V1-G3 Image 2
Visual product photo and picture of the product.
Price: 289.10 $
Specifications
Weight and Dimensions
| Inner (d) MM |
45 |
| Outer (D) MM |
120 |
| Width (B) MM |
136,7 |
| Inner (d) Inch |
1.7717 |
| Outer (D) Inch |
4.7244 |
| Width (B) Inch |
5.3819 |
| Weight (kg) |
3.15 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
120 |
| Overall length carriage (L) mm |
138,7 |
| Dynamic load rating, load direction I: compressive load (I C) |
80000 |
| Static load rating, load direction I: compressive load (I C 0) |
174000 |
| Dynamic load rating, load direction II: tensile load (II C) |
72300 |
| Static load rating, load direction II: tensile load (II C 0) |
117400 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
76900 |
| Static load rating, Load direction III: lateral load (III C 0) |
121800 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Standard carriage for six-row linear recirculating ball bearing and guideway assembly |
Suffix description
| V1 |
Slight Preload |
| G3 |
Precision Class 3 |
