INA KWSE45-L-V2-G3 Image 2

Visual product photo and picture of the product.

INA KWSE45-L-V2-G3 bearing image 2
INA KWSE45-L-V2-G3 bearing image 1
INA KWSE45-L-V2-G3 bearing image 2
INA KWSE45-L-V2-G3 bearing image 3
INA KWSE45-L-V2-G3 bearing image 4
INA KWSE45-L-V2-G3 bearing image 5
Price: 354.28 $
Specifications
Brand INA
Item Number KWSE45-L-V2-G3 INA
Manufacturer Part Number 0028660560340
Also known as KWSE45-L-G3-V2
EAN 4054362958628
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 120
Width (B) MM 172,3
Inner (d) Inch 1.7717
Outer (D) Inch 4.7244
Width (B) Inch 6.7835
Weight (kg) 4.2 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 120
Overall length carriage (L) mm 174,3
Dynamic load rating, load direction I: compressive load (I C) 98000
Static load rating, load direction I: compressive load (I C 0) 236000
Dynamic load rating, load direction II: tensile load (II C) 89000
Static load rating, load direction II: tensile load (II C 0) 159000
Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) 93400
Static load rating, Load direction III: lateral load (III C 0) 168000
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Long carriage for six-row linear recirculating ball bearing and guideway assembly
Suffix description
L Long Carriage
V2 Preload Class 2
G3 Precision Class 3
