INA KWSE30-L-V1-G2 Image 3
Visual product photo and picture of the product.
Price: 216.56 $
Specifications
Weight and Dimensions
| Inner (d) MM |
28 |
| Outer (D) MM |
90 |
| Width (B) MM |
119,1 |
| Inner (d) Inch |
1.1024 |
| Outer (D) Inch |
3.5433 |
| Width (B) Inch |
4.689 |
| Weight (kg) |
1.6 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
90 |
| Overall length carriage (L) mm |
119,3 |
| Dynamic load rating, load direction I: compressive load (I C) |
51000 |
| Static load rating, load direction I: compressive load (I C 0) |
113000 |
| Dynamic load rating, load direction II: tensile load (II C) |
48000 |
| Static load rating, load direction II: tensile load (II C 0) |
85000 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
50000 |
| Static load rating, Load direction III: lateral load (III C 0) |
88000 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Long carriage for six-row linear recirculating ball bearing and guideway assembly |
Suffix description
| L |
Long Carriage |
| V1 |
Slight Preload |
| G2 |
Precision Class 2 |
