INA KWSE25-V2-G3 Image 4
Visual product photo and picture of the product.
Price: 144.46 $
Specifications
Weight and Dimensions
| Inner (d) MM |
23 |
| Outer (D) MM |
70 |
| Width (B) MM |
81,8 |
| Inner (d) Inch |
0.9055 |
| Outer (D) Inch |
2.7559 |
| Width (B) Inch |
3.2205 |
| Weight (kg) |
0.6 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
70 |
| Overall length carriage (L) mm |
81,8 |
| Dynamic load rating, load direction I: compressive load (I C) |
28000 |
| Static load rating, load direction I: compressive load (I C 0) |
67000 |
| Dynamic load rating, load direction II: tensile load (II C) |
26000 |
| Static load rating, load direction II: tensile load (II C 0) |
45000 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
28000 |
| Static load rating, Load direction III: lateral load (III C 0) |
47000 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Standard carriage for six-row linear recirculating ball bearing and guideway assembly |
Suffix description
| V2 |
Preload Class 2 |
| G3 |
Precision Class 3 |
