INA KWSE25-L-V1-G1 Image 5
Visual product photo and picture of the product.
Price: 218.10 $
Specifications
Weight and Dimensions
| Inner (d) MM |
23 |
| Outer (D) MM |
70 |
| Width (B) MM |
104,3 |
| Inner (d) Inch |
0.9055 |
| Outer (D) Inch |
2.7559 |
| Width (B) Inch |
4.1063 |
| Weight (kg) |
0.82 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
70 |
| Overall length carriage (L) mm |
104,3 |
| Dynamic load rating, load direction I: compressive load (I C) |
35300 |
| Static load rating, load direction I: compressive load (I C 0) |
93700 |
| Dynamic load rating, load direction II: tensile load (II C) |
33000 |
| Static load rating, load direction II: tensile load (II C 0) |
62000 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
35000 |
| Static load rating, Load direction III: lateral load (III C 0) |
65000 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Long carriage for six-row linear recirculating ball bearing and guideway assembly |
Suffix description
| L |
Long Carriage |
| V1 |
Slight Preload |
| G1 |
Precision Class 1 |
