INA KWSE20-V0-G1 Image 4
Visual product photo and picture of the product.
Price: 163.23 $
Specifications
Weight and Dimensions
| Inner (d) MM |
20 |
| Outer (D) MM |
63 |
| Width (B) MM |
70,9 |
| Inner (d) Inch |
0.7874 |
| Outer (D) Inch |
2.4803 |
| Width (B) Inch |
2.7913 |
| Weight (kg) |
0.43 kg
|
Product Properties
Data from Schaeffler (medias)
| Width carriage (B) mm |
63 |
| Overall length carriage (L) mm |
71,4 |
| Dynamic load rating, load direction I: compressive load (I C) |
22000 |
| Static load rating, load direction I: compressive load (I C 0) |
52000 |
| Dynamic load rating, load direction II: tensile load (II C) |
21300 |
| Static load rating, load direction II: tensile load (II C 0) |
35300 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) |
21000 |
| Static load rating, Load direction III: lateral load (III C 0) |
35000 |
| ECLASS number |
23-30-04-90 |
| ECLASS2 number |
23-30-04-90 |
| Medias description |
Standard carriage for six-row linear recirculating ball bearing and guideway assembly |
Suffix description
| V0 |
Little To No Preload |
| G1 |
Precision Class 1 |
