INA KRE30-B Image 2
Visual product photo and picture of the product.
Price: 45.44 $
Specifications
Weight and Dimensions
| Inner (d) MM |
15 |
| Outer (D) MM |
30 |
| Width (B) MM |
14 |
| Inner (d) Inch |
0.5906 |
| Outer (D) Inch |
1.1811 |
| Width (B) Inch |
0.5512 |
| Weight (kg) |
0.104 kg
|
Product Properties
| Seal |
No Seal |
| Excenterring |
E - Excenterring with Inbus Mount |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
12 |
| Width (b) mm |
40 |
| Basic dynamic load rating, radial (C r w) |
6800 |
| Basic static load rating, radial (C 0r) |
8700 |
| Speed on permanent grease lubrication (n D G) |
5500 |
| ECLASS number |
23-05-15-02 |
| ECLASS2 number |
23-05-15-02 |
| Medias description |
Stud type track rollers KRE.., with axial guidance via thrust collar or washer, axial plain washers on both sides, with eccentric collar |
Suffix description
| B |
Internal Design Modification, Can Be Used As Standard |
| 2RS |
Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103 |
