INA KRE22-B Image 2
Visual product photo and picture of the product.
Price: 44.61 $
Specifications
Weight and Dimensions
| Inner (d) MM |
13 |
| Outer (D) MM |
22 |
| Width (B) MM |
12 |
| Inner (d) Inch |
0.5118 |
| Outer (D) Inch |
0.8661 |
| Width (B) Inch |
0.4724 |
| Weight (kg) |
0.07 kg
|
Product Properties
| Seal |
No Seal |
| Excenterring |
E - Excenterring with Inbus Mount |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
10 |
| Width (b) mm |
36 |
| Basic dynamic load rating, radial (C r w) |
4500 |
| Basic static load rating, radial (C 0r) |
5400 |
| Speed on permanent grease lubrication (n D G) |
8000 |
| ECLASS number |
23-05-15-02 |
| ECLASS2 number |
23-05-15-02 |
| Medias description |
Stud type track rollers KRE.., with axial guidance via thrust collar or washer, axial plain washers on both sides, with eccentric collar |
Suffix description
| B |
Internal Design Modification, Can Be Used As Standard |
| 2RS |
Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103 |
