INA KR5207-2RS Image 4
Visual product photo and picture of the product.
Price: 117.18 $
Specifications
Weight and Dimensions
| Inner (d) MM |
30 |
| Outer (D) MM |
80 |
| Width (B) MM |
27 |
| Inner (d) Inch |
1.1811 |
| Outer (D) Inch |
3.1496 |
| Width (B) Inch |
1.063 |
| Weight (kg) |
1.2 kg
|
Product Properties
| Seal |
2RS - Rubber Seal on Two Sides |
| Excenterring |
Other Mounting Method |
| Running Surface |
Standard |
Data from Schaeffler (medias)
| Fit diameter of roller stud / stud (d 1) mm |
30 |
| Width (b) mm |
91 |
| Basic dynamic load rating, radial (C r w) |
30500 |
| Basic static load rating, radial (C 0r) |
23600 |
| Fatigue load limit, radial (C ur w) |
1240 |
| Speed on permanent grease lubrication (n D G) |
2800 |
| ECLASS number |
23-05-15-90 |
| ECLASS2 number |
23-05-15-90 |
| Medias description |
Stud type track rollers KR52..-2RS, double row, lip seals on both sides |
Suffix description
| 2RS |
Rubber Seals At Each Side Of The Bearing, Temperature Range -30u2103/+120u2103 |
