INA KBK18X22X22/0-7 Image 3

Visual product photo and picture of the product.

INA KBK18X22X22/0-7 bearing image 3
INA KBK18X22X22/0-7 bearing image 1
INA KBK18X22X22/0-7 bearing image 2
INA KBK18X22X22/0-7 bearing image 3
Price: 11.15 $
Specifications
Brand INA
Item Number KBK18X22X22/0-7 INA
Manufacturer Part Number 0007991736063
EAN 4012802724011
Category Needle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM 18
Outer (D) MM 22
Width (B) MM 22
Inner (d) Inch 0.7087
Outer (D) Inch 0.8661
Width (B) Inch 0.8661
Weight (kg) 0.014 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm 18
Outside diameter of needle roller complement (E w) mm 22
Width (B c) mm 22
Radial Static Load Rating C0r (N) 20700
Radial Dynamic Load Rating Cr (N) 13500
Basic static load rating, radial (C 0r) "20700.0000"
Limiting speed (n G) 22400
ECLASS number 23-05-09-04
ECLASS2 number 23-05-09-04
Medias description Needle roller cage assembly KBK, single row, similar KBK, piston pin bearing
Suffix description
0-7 Micron - Needle Sort
