INA K35X45X30/0-7 Image 4

Visual product photo and picture of the product.

INA K35X45X30/0-7 bearing image 4
INA K35X45X30/0-7 bearing image 1
INA K35X45X30/0-7 bearing image 2
INA K35X45X30/0-7 bearing image 3
INA K35X45X30/0-7 bearing image 4
Price: 17.56 $
Specifications
Brand INA
Item Number K35X45X30/0-7 INA
Manufacturer Part Number 0007181816063
EAN 4012802722994
Category Needle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM 35
Outer (D) MM 45
Width (B) MM 30
Inner (d) Inch 1.378
Outer (D) Inch 1.7717
Width (B) Inch 1.1811
Weight (kg) 0.08 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Outside diameter of needle roller complement (E w) mm 45
Width (B c) mm 30
Radial Static Load Rating C0r (N) 79000
Radial Dynamic Load Rating Cr (N) 53000
Basic static load rating, radial (C 0r) "79000.0000"
Limiting speed (n G) 12300
Reference speed (n u03d1r) 6700
ECLASS number 23-05-09-04
ECLASS2 number 23-05-09-04
Medias description Needle roller cage assembly K, single row
Suffix description
G2 Standard Quality Class For Needles
/0-10 Micron - Needle Sort
