INA K30X35X20-A/0-7 Image 3
Visual product photo and picture of the product.
Price: 9.30 $
Specifications
Weight and Dimensions
| Inner (d) MM |
30 |
| Outer (D) MM |
35 |
| Width (B) MM |
20 |
| Inner (d) Inch |
1.1811 |
| Outer (D) Inch |
1.378 |
| Width (B) Inch |
0.7874 |
| Weight (kg) |
0.025 kg
|
Product Properties
Data from Schaeffler (medias)
| Outside diameter of needle roller complement (E w) mm |
35 |
| Width (B c) mm |
20 |
| Radial Static Load Rating C0r (N) |
44000 |
| Radial Dynamic Load Rating Cr (N) |
24000 |
| Limiting speed (n G) |
15100 |
| Reference speed (n u03d1r) |
8100 |
| ECLASS number |
23-05-09-04 |
| ECLASS2 number |
23-05-09-04 |
| Medias description |
Needle roller cage assembly K, single row |
Suffix description
| A |
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
| /0-7 |
Micron - Needle Sort |
