INA HK1010-AS1-B

Price: 4.62 $

Specifications

Brand	INA
Item Number	HK1010-AS1-B INA
Manufacturer Part Number	0011977030000
EAN	4012802437522
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	10
Outer (D) MM	14
Width (B) MM	10
Inner (d) Inch	0.3937
Outer (D) Inch	0.5512
Width (B) Inch	0.3937
Weight (kg)	0.0039 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Under roller diameter (F w) mm	10
Width (C) mm	10
Basic static load rating, radial (C 0r)	5100
Limiting speed (n G)	24300
Limiting speed for grease lubrication (n G Grease)	14600
Reference speed (n u03d1r)	18700
ECLASS number	23-05-09-05
ECLASS2 number	23-05-09-05

Suffix description

AS1

Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
