INA BK1010-B

Price: 2.91 $

Specifications

Brand	INA
Item Number	BK1010-B INA
Manufacturer Part Number	0011976900000
EAN	4026677166609
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	10
Outer (D) MM	14
Width (B) MM	10
Inner (d) Inch	0.3937
Outer (D) Inch	0.5512
Width (B) Inch	0.3937
Weight (kg)	0.004 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Under roller diameter (F w) mm	10
Radial Static Load Rating C0r (N)	5100
Radial Dynamic Load Rating Cr (N)	4400
Basic static load rating, radial (C 0r)	"5100.0000"
Limiting speed (n G)	24300
Limiting speed for grease lubrication (n G Grease)	14600
Reference speed (n u03d1r)	18700
ECLASS number	23-05-09-06
ECLASS2 number	23-05-09-06
Medias description	Drawn cup needle roller bearings with closed end BK, to DIN 618/ISO 3245

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
