INA HFLZ061014-A-L564 Image 3
Visual product photo and picture of the product.
Price: 23.59 $
Specifications
Weight and Dimensions
| Inner (d) MM |
9,53 |
| Outer (D) MM |
15,88 |
| Width (B) MM |
22,23 |
| Inner (d) Inch |
0.375 |
| Outer (D) Inch |
0.625 |
| Width (B) Inch |
0.875 |
| Weight (kg) |
0.014 kg
|
Product Properties
Data from Schaeffler (medias)
| Under roller diameter (F w) mm |
9,525 |
| Basic static load rating, radial (C 0r) |
5500 |
| Limiting speed for rotating shaft (n GW) |
14000 |
| Limiting speed for rotating outer ring (n GA) |
12000 |
| ECLASS number |
23-05-21-90 |
| ECLASS2 number |
23-05-21-90 |
Suffix description
| A |
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
| L564 |
Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication |
