INA HF3520-L564 Image 3
Visual product photo and picture of the product.
Price: 19.29 $
Specifications
Weight and Dimensions
| Inner (d) MM |
35 |
| Outer (D) MM |
42 |
| Width (B) MM |
20 |
| Inner (d) Inch |
1.378 |
| Outer (D) Inch |
1.6535 |
| Width (B) Inch |
0.7874 |
| Weight (kg) |
0.04 kg
|
Product Properties
Data from Schaeffler (medias)
| Under roller diameter (F w) mm |
35 |
| Permissible torque (M d per) |
121 |
| Limiting speed for rotating shaft (n GW) |
3900 |
| Limiting speed for rotating outer ring (n GA) |
3900 |
| ECLASS number |
23-05-21-90 |
| ECLASS2 number |
23-05-21-90 |
| Medias description |
Drawn cup roller clutches HF, with steel springs |
Suffix description
| L564 |
Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication |
