INA HF1816-L564 Image 2
Visual product photo and picture of the product.
Price: 11.62 $
Specifications
Weight and Dimensions
| Inner (d) MM |
18 |
| Outer (D) MM |
24 |
| Width (B) MM |
16 |
| Inner (d) Inch |
0.7087 |
| Outer (D) Inch |
0.9449 |
| Width (B) Inch |
0.6299 |
| Weight (kg) |
0.016 kg
|
Product Properties
Data from Schaeffler (medias)
| Under roller diameter (F w) mm |
18 |
| Permissible torque (M d per) |
24.1 |
| Limiting speed for rotating shaft (n GW) |
7500 |
| Limiting speed for rotating outer ring (n GA) |
7500 |
| ECLASS number |
23-05-21-90 |
| ECLASS2 number |
23-05-21-90 |
| Medias description |
Drawn cup roller clutches HF, with steel springs |
Suffix description
| L564 |
Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication |
