INA GY1112-KRR-B-AS2/V Image 2
Visual product photo and picture of the product.
Price: 34.24 $
Specifications
Weight and Dimensions
| Inner (d) MM |
44,45 |
| Outer (D) MM |
85 |
| Width (B) MM |
49,2 |
| Inner (d) Inch |
1.75 |
| Outer (D) Inch |
3.3465 |
| Width (B) Inch |
1.937 |
| Weight (kg) |
0.62 kg
|
Product Properties
| Seal |
2F - Standard Seal for Y-bearings |
| Lubrication |
Standard Lubrication |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Outside diameter (D SP) mm |
85 |
| Width (b) mm |
49,2 |
| Radial Static Load Rating C0r (N) |
20400 |
| Radial Dynamic Load Rating Cr (N) |
34500 |
| Basic static load rating, radial (C 0r) |
"20400.0000" |
| ECLASS number |
23-05-08-02 |
| ECLASS2 number |
23-05-08-02 |
| Medias description |
Radial insert ball bearing GY..-KRR-B-AS2/V |
Suffix description
| KRR |
Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B |
Bearing With Spherical Outer Ring |
| AS2/V |
Bearing Outer Ring With Two Lubrication Holes In Offset Planes |
