INA GIL10-UK Image 4
Visual product photo and picture of the product.
Price: 29.52 $
Specifications
| Brand |
INA
|
| Item Number |
GIL10-UK INA
|
| Manufacturer Part Number |
0066351480000 |
| Also known as |
SIL10C
|
| EAN |
4012802526295 |
| Category |
Rod End
|
Weight and Dimensions
| Inner (d) MM |
10 |
| Outer (D) MM |
29 |
| Width (B) MM |
9 |
| Inner (d) Inch |
0.3937 |
| Outer (D) Inch |
1.1417 |
| Width (B) Inch |
0.3543 |
| Weight (kg) |
0.06 kg
|
Product Properties
| Seal |
No Seal |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
19 |
| Radial Static Load Rating C0r (N) |
22000 |
| Width inner ring (B) mm |
9 |
| Radial Dynamic Load Rating Cr (N) |
8640 |
| Basic static load rating, radial (C 0r) |
"22000.0000" |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Rod end with internal thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type F, inner ring curved surface with hard chromium coating, open design, left hand thread |
Suffix description
| UK |
Sliding Contact Surface Hard Chromium/PTFE Composite |
