INA GIKR20-PW Image 3
Visual product photo and picture of the product.
Price: 59.89 $
Specifications
| Brand |
INA
|
| Item Number |
GIKR20-PW INA
|
| Manufacturer Part Number |
0066350240000 |
| Also known as |
SIKB20F
|
| EAN |
4012802526103 |
| Category |
Rod End
|
Weight and Dimensions
| Inner (d) MM |
20 |
| Outer (D) MM |
50 |
| Width (B) MM |
25 |
| Inner (d) Inch |
0.7874 |
| Outer (D) Inch |
1.9685 |
| Width (B) Inch |
0.9843 |
| Weight (kg) |
0.379 kg
|
Product Properties
| Seal |
No Seal |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
40 |
| Radial Static Load Rating C0r (N) |
45600 |
| Width inner ring (B) mm |
25 |
| Radial Dynamic Load Rating Cr (N) |
56600 |
| Basic static load rating, radial (C 0r) |
"45600.0000" |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Rod end with internal thread, right hand thread, maintenance-free, sliding layer: PTFE film brass outer ring, DIN ISO 12240-4, dimension series K, type F, open design |
Suffix description
| PW |
Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film |
