INA GE60-XL-KRR-B-FA164 Image 3
Visual product photo and picture of the product.
Price: 862.91 $
Specifications
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
110 |
| Width (B) MM |
77,9 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
4.3307 |
| Width (B) Inch |
3.0669 |
| Weight (kg) |
1.6 kg
|
Product Properties
| Seal |
2F - Standard Seal for Y-bearings |
| Lubrication |
Standard Lubrication |
| Special Treatment |
E - High Temp Design Up to +250°C |
Data from Schaeffler (medias)
| Outside diameter (D SP) mm |
110 |
| Width (b) mm |
61,9 |
| Locking collar total width (B 1) mm |
77,9 |
| Radial Static Load Rating C0r (N) |
36000 |
| Radial Dynamic Load Rating Cr (N) |
56000 |
| Basic static load rating, radial (C 0r) |
"36000.0000" |
| ECLASS number |
23-05-08-02 |
| ECLASS2 number |
23-05-08-02 |
| Medias description |
Radial insert ball bearings GE..-KRR-B-FA164, spherical outer ring, location by eccentric locking collar, R seals on both sides, for temperatures up to +250°C |
Suffix description
| XL |
X-Life |
| KRR |
Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B |
Bearing With Spherical Outer Ring |
| FA164 |
High Temperature Design Up To +250°C |
